Testing Fuel for Generators: Drilldown of NFPA 110 / ASTM 975 Rules

For those of you who just don’t like to read, or have only a moderate tolerance for reading codes and regulations, we have the done the dirty work for you.

NFPA 110 “Standard for Emergency and Standby Power Systems” is the standard for people who own and operate buildings with emergency generators.  It’s the starting point of what a building owner should consider as good practice, and may go further toward a legal requirement since it is referenced in building codes.

ASTM gets drawn into this through NFPA 110 Part 8.3.7: A fuel quality test shall be performed at least annually using appropriate ASTM standards.



Learn More:  Download the Whitepaper



That is simple enough, but gets a bit more complicated by the detail in the Appendix sections of the standard.  Here we will review each concept

Appendix: A8.3.7 for “Fuel Quality Test”

Fuel Testing: “Limited fuel quality testing performed annually using appropriate ASTM test methods is recommended as a means to determine that existing fuel inventories are suitable for continued long term storage.  Special attention should be paid to sampling the bottom of the storage tank to verify that the stored fuel is as clean and dry as practicable and that water, sediment, or microbial growth on the tank bottom is minimized.  ASTM D975 Standard Specification for Diesel Fuel Oils, contains test methods for existing diesel fuel.”

How do we figure out the “appropriate” ASTM standard, and what is “limited” testing to be performed annually.  The problem is that ASTM D975 Standard Specification of Diesel Fuel Oils covers 7 grades of fuel, 66 ASTM reference standards, and 12 detailed test requirements.

And the standard is designed for evaluation of newly refined fuels, not for evaluating fuels in long term storage.  So there will be various opinions amongst generator manufacturers, testing labs, and other experts as to exactly what is required.

Here is a summary of the 12 tests included in the standard:

Description

ASTM Standard

Flash Point

D93

Water and Sediment

D2709/D1796

Distillation

D86

Viscosity

D445

Ash Content

D482

Sulfur

D5453/D2622/D129

Copper Corrosion

D130

Cetane Index

D976

Cloud Point

D2500

Carbon Residue

D524

Lubricity

D6079/D7688

Conductivity

D2624/D4308

Density

D1298



Fuel Testing for Long Term Storage

Testing of fuel for long term storage is not directly addressed by D975. Fuels stored for more than six months are subject to aging degradation – oxidative products, condensation buildup, and microbiological growth. Here is a summary of the tests typically recommended:

Cetane Index, Cloud Point, Density, Distillation, Flash Point, Sediment and water, Sulfur Content, Oxidative Stability, Particle Contamination

Tank Mid-Level Sample



Description

ASTM Standard

Cetane Index

D976

Cloud Point

D2500

Density

D1298

Distillation

D86

Flash Point

D93

Sediment and Water

D2709/D1796

Sulfur Content

D4294/D5453

Oxidative Stability

ISO 12205

Particle Contamination

D5452 / D7619





Tank Bottom Sample



Description

ASTM Standard

Microorganism Culture

Test Kit

Sediment and Water

D7111

Trace Metals

D7111
